WUZ 100 3,0, 400 V
€11,395.18
Available in approx. 14 days, delivery time 2-4 days
**Vacation Notice!**
We will be on company holidays from May 21, 2026, to May 29, 2026. During this time, our support services and order processing will only be available to a limited extent. Starting May 30, 2026, we will be back as usual and will promptly take care of all incoming orders and inquiries.
Thank you for your understanding and patience.
Thank you for your understanding and patience.
Product information "WUZ 100 3,0, 400 V"
Single-pump sewage lifting unit WUZ 100 3,0 400 V with single-channel impeller pump with fibre cutting insert and large solids handling and comfortable level control, as pre-assembled lifting unit for pumping of domestic or commercial sewage
Model
- polyethylene container with 480 litres capacity and up to 270 litres switching volume
- single-channel impeller pump with fibre cutting insert and large solids handling
- mechanical seal and shaft seal with intermediate oil chamber
- pump housing with flanged outlet bend DN 100
- lateral inlet with loose-type flange DN 150
- additional connection 1 ½“ for manual diaphragm pump
- air vent with loose-type flange DN 100 (Ø 110 mm)
- operation temperature max. 55°C
- operating mode S3 - 25%
- protection grade IP 57 - temporarly submersible
Application
- drainage of sewage from apartment buildings or industrial enterprises etc.
- above-ground installation in frost-free rooms below the backflow level
Scope of delivery
- pre-assembled lifting unit with 3,5 m connection cable to the motor and 3,5 m pneumatic tube to the control
- incl. ZPS1: comfortable, pneumatic level control with microcontroller, LCD plain text display for filling level, maintenance, operating hours, fault message and alarm signal in switchbox for indoor installation
- Attention! Non-return valve, gate valve and further junction fittings optional
Manufacturer Information - "WUZ 100 3,0, 400 V"
