BADU Picco II
€295.00
Available in approx. 14 days, delivery time 2-4 days
Product information "BADU Picco II"
Self-priming circulation pump BADU Picco II for pool sizes of approximately 10 - 30 m³, replaces its predecessor model BADU Picco 5
1~ 230 V
Hmax: 11,0 m
Qmax: 6,2 m³/h
techQ: 5 m³/h
techH: 11 m WS
Pool size: 10 - 30 m³
Motor power: 0.20 kW
Suction/pressure (d): Suction, hose adapter Ø 38 ; pressure, hose adapter Ø 38 specialconnection with hose adapter for 1 1/4" and 1 1/2" hose included.
In the displayed design, the pumps can be used for pool water with up to 0,5% salt concentration (equals 5 g/l).
| Pool equipment: | Circulation pump |
| Pool size in m³: | 10 - 30 |
| Filter size in mm: | 280 - 300 |
| Flow rate Q in m³/h: | 4 |
| Total head H in m WS: | 8 |
| Motor performance in kW (P2): | 0.20 |
| Strainer capacity in l: | approx. 0.5 |
| Strainer basket mesh size in mm: | approx. 2.8 x 2.8 |
| Pool type: | Outdoor pool |
| Installation: | Built-in pool, Above ground pool |
| Class: | Starter |
| Pump casing: | PP |
| Gland housing: | PP TV 40 |
| Impeller: | PA 66 GF 30 / PC |
| Strainer basket: | PP |
| Mechanical seal: | carbon / ceramic / NBR |
| Screws: | stainless steel 1.4301 |
Special motors on request.
The above mentioned pumps can be used for pool water with a salt concentration of up to 0.5%, i. e. 5 g/l.
For higher salt concentrations please contact us.
Also available in AK version
