ZKH 20

• the on-off control is effected automatically by a robust float switch
• if the pump fails (unacceptable high water level in the tank), an alarmswitch can switch off the climate control unit or calorific value boiler (maximum switching capacity 4 A)
• connection for the pressure tube with 6 mm or 9 mm inner diameter
• container volume 1,5 l
• operation temperature max. 50°C

• Drainage of condensation water and condensate from the climate control unit and the gas calorific value boilers with a pH-value up to 2.5

• 5 m tube 9 mm
• integrated non-return valve to prevent the return of condensate
• 2 m power cable with enclosed loose plug

TECHNICAL DATA manufacturer's page
