E-ZW 50 A-2

Product information "E-ZW 50 A-2"

Submersible waste water pump made of stainless steel E-ZW 50 A-2 with float switch

Max. flow rate: 7,5 m³/h
Max. head: 7,5 m
Input power P1: 380 W
Output power P2: 210 W
Solids handling: 10 mm
Pressure outet: 1 1/4" internal thread

Model

  • submersible waste water pump made of stainless steel
  • motor winding with thermal winding protection
  • mechanical seal and additional shaft seal
  • pump housing, motor housing, shaft and suction strainer made of stainless steel, impeller made of polyamide
  • jacket cooled mono-phase motor
  • vertical pressure outlet 1 ¼” FPT
  • version 'A' with mounted float switch
  • protection grade IP 68 – fully submersible
Application
  • pumping of clear water and waste water from pits, drainage manholes, cellars etc.
  • portable pump for emergency
  • drainage drainage of domestic waste water without faeces from showers, washing machines, washbasins etc.
Scope of delivery
  • pump with 10 m power cable and plug

Manufacturer Information - "E-ZW 50 A-2"

Adresse

Zwönitzer Straße 19
08344 Grünhain-Beierfeld
Deutschland
