BADU Gamma 11, 230 V
€835.00
Available in approx. 14 days, delivery time 2-4 days
Product information "BADU Gamma 11, 230 V"
Self-priming filtration circulation pump BADU Gamma 11, 230 V, alternating current version, extremely quiet and with improved hydraulics
1~ 230 Volt
Hmax: approx. 13,5 m
Qmax: approx. 17,4 m³/h
techQ: 11 m³/h
techH: 8 m WS
Power output: 0.45 kW
Inlet / outlet connection(d and Rp): Special union with glue socket d=50 and threaded connection 2"
| Pool equipment: | Circulation pump |
| Flow rate Q in m³/h: | 11 |
| Total head H in m WS: | 8 |
| Motor performance in kW (P2): | 0.45 |
| Strainer capacity in l: | approx. 3 |
| Strainer basket mesh size in mm: | approx. 3.2 x 2.6 |
| Pool type: | Outdoor pool, Indoor pool, Natural pool/swimming pond |
| Installation: | Above ground pool, Built-in pool |
| Class: | PREMIUM |
| Pump casing: | PP GF 30 |
| Diffuser: | PA 66 GF 30/PP GF 30 |
| Impeller: | PP GF 30 |
| Strainer basket: | PP |
| Mechanical seal: | carbon / ceramic / NBR |
| Screws: | stainless steel 1.4301 |
| Intermediate housing: | PP TV 40 |
| Gland housing: | PP TV 40 |
| Lid: | PC, transparent / PA 66 GF 30 |
With the BADU Gamma swimming pool pump you have the usual first-class material quality.It is extremely quiet and has improved hydraulics with optimised water flow. Optional inner or outer threads provide great felxibility during installation.
Swimming pool water circulation through a filter system. The pump can be installed max. 3 m above or below water level.
Monoblock-type pump with integrated strainer tank. The bellow-type mechanical seal is mounted on a plastic shaft protector sleeve. Motor/pump shaft has no contact with the pool water providing complete electrical separation.
Special motors on request.
The above mentioned pumps can be used for pool water with a salt concentration of up to 0.5%, i. e. 5 g/l.
For higher salt concentrations please contact us.
Also available in AK version
