BADU 47/10
€315.00
Available, delivery time: approx. 2-4 days
Product information "BADU 47/10"
Non self-priming pool circulation pump BADU 47/10 We., alternating current version, with self-draining unit and a flow rate of approximately 11 m³/h the perfect jet pumps for jacuzzis and whirlpools. With cable, without plug.
1~230 Volt
Hmax= 11 m
Qmax= 15.5 m³/h
techQ: 11 m³/h
techH: 8 m WS
Pool size: 1 - 30 m³
Power output: 0.45 kW
Inlet / outlet connection d (mm): 63 / 50
| Pool equipment: | Circulation pump |
| Pool size in m³: | 1 - 30 |
| Flow rate Q in m³/h: | 11 |
| Total head H in m WS: | 8 |
| Motor performance in kW (P2): | 0.45 |
| Pool type: | Whirlpool |
| Pump casing: | PP TV 40 |
| Gland housing: | PP TV 40 |
| Mechanical seal: | carbon / ceramic / NBR |
| Screws: | brass / stainless steel |
Connection option for BADU 46 medium-size jet pump.
For bath tubs, whirlpools and spa facilities.
The BADU 47 pumps empty remaining water automatically. Flow rate is from 6 m³/h to 23 m³/h at 8 m, the ideal pumps for jacuzzis and spas.
Monoblock-type pump. The bellow-type mechanical seal is mounted on a plastic shaft protector sleeve. Motor/pump shaft has no contact with the pool water providing complete electrical separation.
Special motors on request.
The above mentioned pumps can be used for pool water with a salt concentration of up to 0.5%, i. e. 5 g/l.
For higher salt concentrations please contact us.
Also available in AK version
